Install a LEMP Stack on Ubuntu 16.04

Updated by Linode Written by Linode

Contribute on GitHub

Report an Issue | View File | Edit File

LEMP Server on Ubuntu 16.04

What is a LEMP Stack?

The LAMP stack (Linux, Apache, MariaDB, and PHP) is a popular server configuration for developing and hosting web applications. The four components of the stack are not tightly coupled, making it possible to substitute your preferred technologies. The LEMP stack is a common variant in which the Apache web server is replaced by NGINX.

Before You Begin

  1. You will need root access to the system, or a user account with sudo privilege.
  2. Set your system’s hostname.
  3. Update your system.

Installation

NGINX

These steps install NGINX Mainline on Ubuntu from NGINX Inc’s official repository. For other distributions, see the NGINX admin guide. For information on configuring NGINX for production environments, see our Getting Started with NGINX series.

  1. Open /etc/apt/sources.list in a text editor and add the following line to the bottom. Replace CODENAME in this example with the codename of your Ubuntu release. For example, for Ubuntu 18.04, named Bionic Beaver, insert bionic in place of CODENAME below:

    /etc/apt/sources.list
    1

    deb http://nginx.org/packages/mainline/ubuntu/ CODENAME nginx
  2. Import the repository’s package signing key and add it to apt:

    sudo wget http://nginx.org/keys/nginx_signing.key
    sudo apt-key add nginx_signing.key

  3. Install NGINX:

    sudo apt update
    sudo apt install nginx

  4. Ensure NGINX is running and and enabled to start automatically on reboot:

    sudo systemctl start nginx
    sudo systemctl enable nginx


MariaDB

  1. Install the MariaDB server and MySQL/MariaDB-PHP support. You may be prompted to set a root password during installation.

    sudo apt install mariadb-server php7.0-mysql

  2. Run the mysql_secure_installation script:

    sudo mysql_secure_installation


    If you were not prompted to create a MySQL root user password when installing MariaDB, answer the script Y to set one.

    Answer Y at the following prompts:

    • Remove anonymous users?
    • Disallow root login remotely?
    • Remove test database and access to it?
    • Reload privilege tables now?
  3. Log in to MariaDB’s SQL shell. Enter the root user’s password when prompted.

    mysql -u root -p

  4. Create a test database and user with access permission. Replace testdb and testuser with appropriate names for your setup. Replace password with a strong password.

    CREATE DATABASE testdb;
    CREATE USER 'testuser' IDENTIFIED BY 'password';
    GRANT ALL PRIVILEGES ON testdb.* TO 'testuser';
    quit

PHP

  1. Install the PHP FastCGI Processing Manager, which will bring in the core PHP dependencies:

    sudo apt install php7.0-fpm

  2. Tell PHP to only accept URIs for files that actually exist on the server. This mitigates a security vulnerability where the PHP interpreter can be tricked into allowing arbitrary code execution if the requested .php file is not present in the filesystem. See this tutorial for more information about this vulnerability.

    sudo sed -i 's/;cgi.fix_pathinfo=1/cgi.fix_pathinfo=0/g' /etc/php/7.0/fpm/php.ini

  3. Ownership of PHP’s listening UNIX sockets is set to www-data by default, but they need to match the user and group NGINX is running as. If you installed NGINX from the NGINX repository as done above, NGINX will be using the nginx user and group. Change the listen variables in www.conf to that:

    sudo sed -i 's/listen.owner = www-data/listen.owner = nginx/g' /etc/php/7.0/fpm/pool.d/www.conf
    sudo sed -i 's/listen.group = www-data/listen.group = nginx/g' /etc/php/7.0/fpm/pool.d/www.conf


Set an NGINX Site Configuration File

  1. Create a root directory where the site’s content will live. Replace example.com with your site’s domain.

    sudo mkdir -p /var/www/example.com/

  2. Disable the default site configuration provided with the package as an example. Or if you have no use for it, delete it.

    sudo mv /etc/nginx/conf.d/default.conf /etc/nginx/conf.d/default.conf.disabled

  3. Website configuration files should be kept in /etc/nginx/conf.d/. Create a configuration file for your site. Again replace example.com with your site’s domain.

    /etc/nginx/conf.d/example.com.conf
     1
     2
     3
     4
     5
     6
     7
     8
     9
    10
    11
    12
    13
    14
    15
    16
    17
    18

    server {
        listen         80 default_server;
        listen         [::]:80 default_server;
        server_name    example.com www.example.com;
        root           /var/www/example.com;
        index          index.html;

        location / {
          try_files $uri $uri/ =404;
        }

        location ~* \.php$ {
          fastcgi_pass unix:/run/php/php7.0-fpm.sock;
          include         fastcgi_params;
          fastcgi_param   SCRIPT_FILENAME    $document_root$fastcgi_script_name;
          fastcgi_param   SCRIPT_NAME        $fastcgi_script_name;
        }
    }

    Here’s a breakdown of the server block above:

    • NGINX is listening on port 80 for incoming connections to example.com or www.example.com.

    • The site is served out of /var/www/example.com/ and it’s index page (index.html) is a simple .html file. If your index page will use PHP, substitute index.php for index.html.

    • try_files tells NGINX to verify that a requested file or directory actually exist in the site’s root filesystem before further processing the request. If it does not, a 404 is returned.

    • location ~* \.php$ means that NGINX will apply this configuration to all .php files (file names are not case sensitive) in your site’s root directory, including any subdirectories containing PHP files.

    • The * in the ~* \.php$ location directive indicates that PHP file names are not case sensitive. This can be removed if you prefer to enforce letter case.

    • fastcgi_pass specifics the UNIX socket where PHP listens for incoming connections from other local processes

    • include fastcgi_params tells NGINX to process a list of fastcgi_param variables at /etc/nginx/fastcgi_params.

    • The fastcgi_param directives contain the location (relative to the site’s root directory) and file naming convention of PHP scripts to be served when called by NGINX.

Test the LEMP Stack

  1. Restart PHP and reload the NGINX configuration:

    sudo systemctl restart php7.0-fpm
    sudo nginx -s reload

  2. Create a test page to verify NGINX can render PHP and connect to the MySQL database. Replace the "testuser" and "password" fields with the MySQL credentials you created above.

    /var/www/example.com/test.php
     1
     2
     3
     4
     5
     6
     7
     8
     9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24

    <html>
    <head>
        <h2>LEMP Stack Test</h2>
    </head>
        <body>
        <?php echo '<p>Hello,</p>';

        // Define PHP variables for the MySQL connection.
        $servername = "localhost";
        $username = "testuser";
        $password = "password";

        // Create a MySQL connection.
        $conn = mysqli_connect($servername, $username, $password);

        // Report if the connection fails or is successful.
        if (!$conn) {
            exit('<p>Your connection has failed.<p>' .  mysqli_connect_error());
        }
        echo '<p>You have connected successfully.</p>';
        ?>
    </body>
    </html>

  3. Go to http://example.com/test.php in a web browser. It should report that You have connected successfully. If you see an error message or if the page does not load at all, re-check your configuration.

  4. Remove the test file once the stack is verified to be working correctly:

    sudo rm /var/www/example.com/test.php
